Description
Key Features:
- Large display.
- Backlight for work in dim areas.
- Min / Max to record signal fluctuations.
- Ergonomic overmolded housing with integrated probe holders.
- Free your hands with the optional TPAK magnetic hanger.
- Auto and Manual ranging.
- Meets Measurement Category 1000 V CAT III and Category IV 600 V safety standards.
Specifications: |
||
Voltage DC | Range | 6.000 V – 1000 V |
Best accuracy | ±(0.3% + 1) | |
Best resolution | 0.1 mV | |
Voltage AC | Range | 600.0 mV – 1000V |
Best accuracy | ±(2.0% + 2) | |
Best resolution | 1.0 mV | |
Amps AC | Range | 60.00 mA – 10 A |
Best accuracy | 2.5% + 2 | |
Best resolution | 0.01 mA | |
Amps DC | Range | 60.00 mA – 10A |
Best accuracy | 1.5% + 2 | |
Best resolution | 0.01 mA | |
Resistance | Range | 600.0 Ω – 50 MΩ |
Best accuracy | ±(0.5% + 1) | |
Best resolution | 0.1 Ω | |
Capacitance | Range | 1nF – 9,999 μF |
Best accuracy | ±(1.2% + 2) | |
Best resolution | 1 nF | |
Frequency | Range | 99.99Hz – 99.99kHz |
Best accuracy | ±(0.1% + 1) | |
Best resolution | 0.01 Hz | |
Safety | ANSI / ISA S82.02.01, CSA C22.2–1010.1, IEC 61010 to 1000 V Measurement Category III, 600 V Measurement Category IV | |
Certifications | CSA, TÃœV (EN61010), Î , (N10140) | |
General Specifications | ||
Maximum voltage between any terminal and earth ground | 1000 V | |
Surge protection | 8 kV peak per IEC 61010 | |
Ω Fuse for mA inputs | 440 mA, 1000 V FAST Fuse | |
Ω Fuse for A inputs | 11 A, 1000 V FAST Fuse | |
Display | Digital | 6000 counts, updates 4/sec |
Bar graph | 33 segments, updates 32/sec | |
Frequency | 10,000 counts | |
Capacitance | 1,000 counts | |
Altitude | Operating | 2,000 meters |
Storage | 12,000 meters | |
Temperature | Operating | -10°C to + 50°C |
Storage | -40°C to + 60°C | |
Temperature coefficient | 0.1 x (specified accuracy / °C (< 18°C or > 28°C) | |
Electromagnetic compatibility (EN 61326–1:1997) |
In an RF field of 3 V/M, accuracy = specified accuracy except in temperature: specified accuracy ±5°C (9°F) |
|
Relative humidity (maximum non-condensing) |
90% to 35°C 75% to 40°C 45% to 50°C |
|
Battery life | 400 hours typical (alkaline) | |
Size (H x W x L) | 4.3 x 9 x 18.5 cm | |
Weight | 420 g |
